Коды ошибок рефрижераторных установок Mitsubishi TU 73.
E01 evaporater fan (F2 & F4).
E04 RPM sensor (F5 & F6).
E06 Fuse F7.
E09 Diesel/standby switch.
E10 High pressure cut-out.
E11 Low pressure switch (optional).
E15 Defrost circuit.
E20 Oil pressure switch.
E21 Water temp switch.
E23 Incorrect rpm.
E24 Does not start (fuel supply).
E29 Does not start (engine function fault).
E30 Front door not closed.
E31 Does not start (engine function fault).
E32 Alternater not charging.
E33 Heat circuit.
E50 Sensor defect.
E73 Does not start (engine function fault).
E99 Remote failure.
Поделиться ссылкой:
Alarm
Trouble
Code
Magnet clutch
fuse has blown.
Throttle solenoid
fuse has blown.
Load drive circuit
fuse has blown.
Commercial power
supply is defective.
High pressure
protection device
tripped.
Discharge gas temperature
is abnormally high.
Refrigerant
shortage.
Low-pressure is abnormally
low or abnormal
low-pressure sensor .
Abnormal
high-pressure sensor.
Engine cooling
water tempera-
ture is abnormally
high.
Engine speed is
abnormally low.
Engine start
failure.
Engine speed is
abnormally high.
Condensing unit
front panel open.
Motor over-current
protection device
tripped.
Poor alternator
generation.
Evaporator electric
heater protection device
tripped. (Optional)
Engine clutch overheat
protection device tripped.
*This alarm cannot be reset because it could result in a fire. When this alarm has occurred,
contact a dealer.
Countermeasure
Fuse F3 has blown. Replace fuse F3 (10 A) in the
control box. If trouble persists after replacement,
ask a dealer for inspection.
Fuse F9 has blown. Replace fuse F9 (30 A) in the
control box. If trouble persists after replacement,
ask a dealer for inspection.
Fuse F2 has blown. Replace fuse F2 (15 A) in the
control box. If trouble persists after replacement,
ask a dealer for inspection.
Commercial power supply is in failure or
disconnected. Check the power supply.
High-pressure switch has tripped.
(1) Open the front panel and inspect the condenser
fan drive system for any abnormality.
(2) Check to see if the condenser coil is fouled
heavily. If so, cleanse it with water.
(High-pressure cleansing is prohibited.)
Refrigerant temperature at the compressor discharge side
has reached the protective temperature. Consult a dealer.
Refrigerant quantity is extremely low.
Ask a dealer for inspection.
Refrigerant pressure at compressor suction side has
dropped to the protective pressure, or low-pressure sensor
is in failure. Ask a dealer for inspection.
High-pressure sensor is in failure.
Ask a dealer for inspection.
Engine water temperature switch has tripped. Inspect the
water quantity in the reservoir tank and replenish if
necessary. Also inspect and clean the radiator (heat
exchanger placed at right as seen facing the refrigeration
Engine speed is extremely low.
Ask a dealer for inspection
Inspect the fuel tank to see if fuel is reserved.
If fuel is reserved, inspect the battery.
Engine speed has increased far beyond the
setting value. Ask a dealer for inspection.
Front panel of condensing unit is open. Close
the panel completely.
Motor over-current protection device has
tripped. Ask a dealer for inspection.
Power generation signal from the alternator is not
detected. When the unit operation has been stopped
due to this error, ask a dealer for inspection.
Electric heater protection device has tripped.
Ask a dealer for inspection.
Engine clutch overheat prevention device has tripped.
Ask a dealer for inspection.
— 68 —
9 For emergency
Alarm
Unit
Lamp
Condition
On
Unit stops.
Unit operation continues.
(Emergency
Blinking
operation with low
engine speed only)
On
Unit stops.
Unit stops.
Blinking
(Automatic operation
resume)
On
Unit stops.
Unit stops.
Blinking
(Automatic operation
resume)
Unit stops.
On
On
Unit stops.
Blinking
Unit stops.
On
Unit stops.
Unit stops.
(Automatic operation
On
resume repeats up
to 9 times.)
Unit stops.
On
On
Unit stops.
Unit stops.
Blinking
(Automatic operation
resume)
Unit stops.
(Automatic operation
On
resume repeats up
to 2 times.)
Blinking
Unit operation
(or On with
continues.
battery
(Unit stops if battery
voltage drop)
voltage is low.)
Unit stops.
(Automatic
Blinking
operation
resume)
Unit* stops.
On
1
2
3
4
5
6
7
8
9
1 0
